Assembler and Disassembler

In developing and verifying BLIMP processors, a RISCV assembler and disassembler were also created in C++. The disassembler allowed instruction traces to clearly display instructions in the pipeline when being tested, and the assembler allowed processor tests to be written in assembly (being converted to bits before being used as a stimulus for the processor). These utilities were also used in the functional-level processor, which needed to be able to identify instructions in order to execute their semantics.

When developing these utilities, extensibility and performance were two main goals. Accordingly, the current implementation strives to achieve the following:

• Adding support for new instructions should require minimal changes

• String operations should be avoided if possibe, to make operations quick (ex. when identifying a binary instruction)

All of these utilities are implemented in the asm directory.

Instruction Identification

Our assembler/disassembler utilities need some internal representation of each instruction type, which should contain all the information necessary to determine whether a string or binary instruction is of that particular type. This information is known as the instruction’s specification, and is defined in inst.h:

typedef struct {
  inst_name_t name;
  std::string assembly;
  uint32_t    match;
  uint32_t    mask;
} inst_spec_t;

This includes:

• The instruction’s name (a unique enumeration to identify the instruction type)

• A template of how the instruction is used in assembly, containing the fields in their appropriate position (ex. addi rd, rs1, rs2)

• 32-bit match and mask values. To understand these values, consider each instruction’s bits as a combination of those that uniquely identify the instruction (ex. the opcode, func3 / func7 fields, etc.), and those that encode the instruction’s arguments (ex. the value of rs1). match contains the identification bits of the instruction (with non-identification bits set to 0), and the bits in mask are set to identify the location of identification bits in the instruction. In this way, for any given instruction, inst & mask should equal match for any instance of that instruction, and not for an instance of a different instruction

Instruction specifications are given for all possible instructions (currently implemented up to RV32IM). To identify the specification for a given assembly string, we can compare the first space-delimited word of the string to the first word in the template assembly; these will be the instruction names. To identify the specification for a given binary instruction inst, we can find the specification for which inst & mask == match. This implementation additionally allows for ease of extensibility; if a designer wished to add a new (possibly custom) instruction to be identified, they would only need to add a new value to the inst_name_t enum, and define the instruction specification in inst.h.

Instruction Generation

Once we’ve identified the specification for a given instruction, we can use the template assembly to convert from a binary representation to a string or vice versa.

Assembly String from Binary Instruction

When generating an assembly string, the base of the string is already given in the instruction template; all that’s left to do is replace the template fields (ex. "rs1") with the values given in binary. For all instruction fields used in RV32IM, a get_*_id function is defined in fields.h (implemented in fields.cpp) to extract the correct string value for the field, given a binary representation (with a get_* function often being used just to obtain the numberic value). For example, the get_rd_id function takes in a binary instruction (as a uint32_t), and returns the string of the value in the rd position in the instruction. To disassemble an instruction, we accordingly take the base assembly template, and iterate through the template argument fields, using the corresponding get_*_id function to replace the field with its string value. The mapping of field strings to get_*_id functions is defined in disassemble.cpp.

Function Signatures

Most of the get_*_id functions only take in the binary instruction as a uint32_t. However, some instructions require the PC in addition to the instruction to be properly represented as a string. An example of this is the address in a jump; the string representation should show the absolute address, whereas the instruction only encodes the offset. These are maintained in a separate mapping, and are checked as well when finding the correct function to replace a field in the template assembly.

Binary Instruction from Assembly String

When generating a binary instruction, the base of the instruction is already given by the match provided in the specification; this encodes all of the instruction-specific bits, such that we only need to provide the bits for the arguments. For all instruction fields used in RV32IM, a *_mask function is defined in fields.h (implemented in fields.cpp) that takes the string value of the field, and returns a 32-bit value containing the value in the appropriate bits (with all other bits set to 0). For example, the rd_mask function takes in a string representing the value for rd, and returns a uint32_t with the value for rd encoded in bits 7 through 11. To assemble an instruction, we accordingly take the match, and iterate through the fields in the assembly string; by matching them with the fields in the template assembly, we can use a corresponding *_mask function to turn the string values into bits, and bitwise-OR the results with our match to build up the instruction with its arguments. The mapping of field strings to *_mask functions is defined in assemble.cpp.

Control Flow Target Handling

Similar to the disassembler, a separate mapping is maintained to support instructions that require both the field’s string value and the current PC to determine the correct value.

This implementation naturally extends to support additional instructions. If the instruction uses fields that already have *_mask and get_*_id functions, no more work is needed; once the instruction specification is added in inst.h, assembly and disassembly can be done. If the instruction uses new fields, the user would only have to implement the *_mask and get_*_id functions for the new fields, and add them to the known functions in assemble.cpp and disassemble.cpp, respectively.
