Decode Issue Unit (DIU)

DecodeIssueUnit L7

The level 7 Decode-Issue Unit (DIU L7) is responsible for decoding instructions, renaming architectural registers to physical registers, evaluating source operand values, and issuing instructions to the appropriate pipe using issue queues to allow for superscalar issue, which is the key improvement over the L6 DIU. To support this, the rename table now has two lookup ports for each issue queue, such that operand ready status is looked up via the issue queues instead of right after decoding. The register file now also has two read ports per issue queue to allow for independent operand value reads. The issue queues support single-cycle latency bypassing if the operand becomes ready via the complete interface, as well as full queue bypassing for control XU’s to keep the single-cycle branch resolution latency.

Instruction Router for Issue Queues: SSInstRouter

The instruction router for issue queues (SSInstRouter) is responsible for directing each decoded instruction to the appropriate issue queue based on which pipes support the instruction’s micro-op and which queues have the most available capacity. This is similar to the previous InstRouter used for single-issue routing, but extended to handle the case where multiple issue queues may support the same instruction.

The router is composed of two submodules. First, one SSInstRouterUnit is instantiated per pipe, each parameterized with the ISA subset supported by that pipe. Each unit checks whether the incoming micro-op is compatible with its pipe’s ISA subset using the in_subset function across all supported RISC-V operations, producing a per-pipe iq_compat_op signal that is asserted when the instruction is valid and the pipe supports it.

Second, the IQPicker module consumes the compatibility signals from all router units along with the iq_avail_slots count from each issue queue. It selects the compatible queue with the most available slots, breaking ties in favor of the lowest-indexed pipe. The picker outputs a one-hot grant vector (iq_val) indicating which queue the instruction should be sent to, as well as an any_gnt signal indicating that at least one compatible queue was found.

The top-level SSInstRouter module asserts the xfer handshake signal only when a compatible queue is selected and that queue’s iq_rdy signal indicates it can accept the instruction. This ensures backpressure is properly propagated when all compatible queues are full.

In-Order Issue Queue: IssueQueueInOrder

The in-order issue queue (IssueQueueInOrder) is a circular FIFO that buffers decoded instructions and issues them to the execute stage strictly in program order once both source operands are ready. Each issue queue has its own pair of rename table lookup ports and register file read ports, enabling independent operand resolution per queue.

The queue maintains insert and dequeue pointers (ins_ptr and deq_ptr) to manage its circular buffer of entries. On insertion, the instruction’s decoded fields (micro-op, physical register addresses, immediate, PC, sequence number, etc.) are stored at the insert pointer. The avail_slots output communicates the remaining capacity to the SSInstRouter for load-balancing decisions.

On the dequeue side, the queue looks up the source physical registers of the head-of-queue instruction in the rename table via the rt_lookup_pending signals. If neither source operand is pending (i.e., both are ready), the queue asserts the dequeue handshake and drives the operand values read from the register file onto the execute interface, along with the rest of the instruction fields. In-order issue is enforced by only ever considering the instruction at the dequeue pointer for issue.

The queue also supports a same-cycle bypass path: when the queue is empty and both the insert and dequeue handshakes are active simultaneously, the incoming instruction can bypass the entry storage entirely and be issued directly to the execute stage, avoiding the one-cycle latency of writing to and reading from the queue. This is particularly important for control-flow instructions (branch and jump), where the bypass path (enabled via the p_bypass parameter) keeps the branch resolution latency to a single cycle. When p_bypass is set, the queue operates in a fully stateless mode, acting as a combinational pass-through that gates the instruction based solely on operand readiness, with no internal storage.

DecodeIssueUnit L8

The Level 8 Decode-Issue Unit (DIU L8) extends the L7 DIU with superscalar frontend decode, processing p_num_fe_lanes instructions per cycle in parallel. As shown in the diagram below, each frontend lane has its own InstDecoder and ImmGen instance (wrapped in SSDecoder) that decode the instruction word and generate the immediate value independently. The SSRenameTableL3 allocates physical registers for all lanes simultaneously, with inter-lane forwarding of destination register mappings to handle intra-block dependencies (described further below). Instructions are then routed from the p_num_fe_lanes input lanes to p_num_pipes output issue queues via a two-stage crossbar: the SSInstMapper computes the lane-to-pipe mapping using an iSLIP-based matching engine, and the SSDIURouter muxes instruction data according to the mapping. Each issue queue can be either the in-order IssueQueueInOrder used in L7 or a new out-of-order IssueQueueOOO (described below), with its own register file read ports for independent operand resolution.

Instruction Window FIFO: DIUFifo

The DIU L8 uses a DIUFifo to buffer fetched instruction blocks between the fetch and decode-issue stages. The FIFO wraps a FifoBypass and presents an instruction-window abstraction with per-lane editable head state. Each lane in the head entry carries a 2-bit inst_status field with three states: INVALID (2’b00), READY (2’b01), and DISPATCHED (2’b10).

The decode-issue pipeline reads the head entry each cycle and writes back per-lane status edits: lanes that fail instruction checks are marked INVALID, and lanes that successfully dispatch are marked DISPATCHED. These edits are maintained in shadow registers that overlay the FIFO head entry and reset when the head is popped or the FIFO is cleared. The head entry is popped (and the window advances) only when every lane in the current entry is either invalid, dispatching this cycle, or already dispatched.

The FIFO is reset on ctrl_flow_sub.redirect_val (an external redirect from an XU) and cleared on ctrl_flow_pub_val_comb (an internal redirect from a JAL/JALR dispatch in the current window).

Instruction Check Stages

Dispatch eligibility is evaluated through four cascaded InstCheck stages per lane, each gating on the result of the previous stage:

• S1 – Validity: Checks that the FIFO entry is valid (F_curr[i].val), the instruction status is not INVALID, and the decoder recognizes the instruction. This is the first filter and its pass output gates all subsequent stages.

• S2 – Control instruction ordering: Enforces ordering constraints around control flow instructions (branches and jumps). The DIU scans the current window for the oldest undispatched control instruction (JAL/JALR/BRX) using wrap-around-safe sequence number age comparisons via SSSeqAge. For BRX instructions, younger instructions in the window are blocked from dispatching until the branch’s source operands are ready and it can be dispatched. For JAL/JALR instructions, the oldest control instruction must be able to dispatch (pass S4) before younger instructions proceed. Instructions younger than the oldest control instruction are also blocked when a redirect is pending on ctrl_flow_sub.

• S3 – Physical register allocation: Checks that a free physical register is available for allocation (via alloc_rdy) for instructions that write a destination register. Lanes are checked in order, with each lane gating on the previous lane’s allocation success to prevent over-allocation.

• S4 – Structural hazard (crossbar routing): Checks that the instruction was successfully routed to an issue queue by the SSInstMapper (i.e., the lane_val signal is asserted). Lanes are again checked in order to preserve dispatch ordering.

The invalidate outputs from all four stages are OR-reduced per lane to determine whether to mark a lane INVALID in the instruction window.

Control Flow Handling

Because multiple instructions are decoded simultaneously, the DIU L8 must handle the case where the current window contains control flow instructions alongside younger instructions that should not be issued. The DIU scans all lanes each cycle to find the oldest undispatched control instruction (JAL/JALR/BRX), tracking its lane index, sequence number, and whether it is a branch (BRX) via oldest_ctrl_inst_found, oldest_ctrl_inst_idx, and oldest_ctrl_inst_is_brx.

For JAL/JALR instructions, when the oldest control instruction dispatches, the DIUCtrlFlowPublisher computes the jump target and publishes a redirect on the ctrl_flow_pub interface via the ControlFlowNotif. For JAL instructions, the target is PC + imm; for JALR, the target is (rs1 + imm) & ~1, where rs1 is read from the control pipe’s register file port. When branch prediction is enabled, the publisher also checks whether the JAL was already predicted taken (via the predicted_taken flag propagated from the fetch unit); if so, the redirect is suppressed since the fetch unit is already fetching from the correct target, and only a bp_update_val is asserted to confirm the prediction to the branch predictor. For unpredicted JALs and all JALRs, redirect_val is asserted. The redirect signals are combinational, relying on the downstream control flow arbiter to break the combinational loop back to the fetch unit.

The ctrl_flow_pub_val_comb signal is used internally to clear the FIFO immediately when a jump dispatches.

For BRX instructions, the DIU checks whether the oldest control instruction’s source operands are ready by performing a rename table lookup through a dedicated port (port index p_num_pipes). If the sources are not ready, the S2 check blocks all instructions in the window from dispatching, ensuring no instruction younger than an unresolved branch is speculatively issued.

When a redirect arrives on the ctrl_flow_sub interface (from an XU), the FIFO is reset, discarding all instructions in the current window.

Instruction-to-Pipe Mapper: SSInstMapper

The instruction-to-pipe mapper (SSInstMapper) computes a one-to-one mapping from p_num_input_lanes front-end lanes to p_num_pipes back-end pipes using a shared ISLIPCore matching engine, which implements a modified version of the iSLIP algorithm. The mapper replaces the single-instruction SSInstRouter from L7 and handles the multi-lane case.

First, a compatibility matrix is computed: for each (input lane, output pipe) pair, iq_compat_op is asserted when the instruction’s micro-op is supported by the pipe’s ISA subset (via in_subset checks), the instruction is valid, the queue is ready, and the queue has available slots. For pipes with p_pipe_bypass set, compatibility additionally requires that the instruction’s source operands are both ready (since bypass pipes issue combinationally with no buffering).

The matching is performed by ISLIPCore over p_num_iter iterations (defaulting to p_num_fe_lanes), each consisting of two phases:

• Grant phase (age-based): Each output pipe examines all compatible, unmatched inputs and grants to the oldest one, determined by an AgePE priority element using wrap-around-safe age comparison via the oldest committed sequence number from SSSeqAge.

• Accept phase (slot-based): Each input lane examines all outputs that granted to it and accepts the one with the most available issue queue slots, determined by a SlotsPE priority element. Ties are broken in favor of the lower-indexed pipe.

After each iteration, matched inputs and outputs are removed from consideration (via input_free and output_free masks), and the next iteration attempts to match the remaining unmatched ports. The final match results across all iterations are OR-reduced to produce per-pipe iq_val and route_idx signals (selecting which lane feeds each pipe) and per-lane lane_val and lane_to_pipe_map signals (indicating which pipe the lane was matched to, if any).

Data Router: SSDIURouter

The SSDIURouter is a pure data router that muxes per-lane instruction data to per-pipe outputs based on the mapping produced by SSInstMapper. It consumes the route_idx, iq_val, and lane_to_pipe_map signals from the mapper and produces per-pipe iq_msg and iq_ins_try outputs for the issue queues. It also computes dispatch_go per lane, which is asserted when the lane passes all instruction checks and the target issue queue is ready.

Issue Queue Selection and Configuration

Each pipe’s issue queue type is determined by a set of configuration parameters:

• ``p_pipe_bypass``: When set to 1, all pipes use bypass-mode issue queues (IssueQueueInOrder with p_bypass=1); when 0 (the default), only the control-subset pipe (the one whose ISA subset exactly matches p_ctrl_subset) uses bypass mode.

• ``p_mem_subset``: Defines the memory instruction subset. Pipes whose ISA subset intersects p_mem_subset are automatically forced to use in-order issue queues, since there is no load-store queue in the memory execute unit.

• ``p_all_iq_in_order``: When set, all issue queues use in-order issue regardless of pipe type.

Pipes that are neither bypass nor forced in-order use the out-of-order IssueQueueOOO described below.

Out-of-Order Issue Queue: IssueQueueOOO

The out-of-order issue queue (IssueQueueOOO) is a drop-in alternative to IssueQueueInOrder that dequeues the oldest ready instruction rather than blocking on the in-order head. Source operand pending status is provided at insert time and tracked internally; the queue monitors completion notifications to clear pending bits, removing the need for rename-table lookups at dequeue.

The queue maintains a flat array of entries with per-entry valid bits and per-entry source pending bits. On insertion, a free slot is selected via a priority encoder. On dequeue, the queue computes per-entry readiness (both sources not pending, with same-cycle completion bypass) and selects the oldest ready entry using XOR-based wrap-around-safe age comparison against the oldest_seq_num from SSSeqAge. An entry j is considered older than entry i when (seq[j] < seq[i]) ^ (seq[j] < oldest) ^ (seq[i] < oldest). The oldest ready entry is priority-encoded to produce the dequeue index.

Like IssueQueueInOrder, the OOO queue supports a same-cycle bypass path when the queue is empty, issuing the incoming instruction directly if its sources are ready. When p_bypass is set, the queue operates in fully stateless bypass mode, identical to the in-order bypass behavior.

Sequence Age Tracker: SSSeqAge

The SSSeqAge module tracks the oldest committed sequence number by monitoring the commit interface. This value is shared between the SSInstMapper (for age-based grant priority) and the IssueQueueOOO instances (for oldest-ready selection), providing consistent wrap-around-safe age comparison across the decode-issue pipeline.

Register File Configuration

The p_regfile_per_pipe parameter controls register file organization. When cleared (the default), a single shared SSRegfileL2 with p_num_pipes lookup ports is instantiated. When set, one SSRegfileL2 per pipe is instantiated, each with a single lookup port. Both configurations use p_num_be_lanes write ports driven by the completion interface.

Rename Table with Allocated Destination Register Forwarding: SSRenameTableL3

The SSRenameTableL3 extends the previous rename table to support p_num_fe_lanes simultaneous allocations with inter-lane destination register forwarding, as shown in the first image above. The core data structures – a 31-entry rename table mapping architectural registers to physical registers with pending bits, and a free list tracking available physical registers – are unchanged from the single-lane version.

For multi-lane allocation, each lane has its own PriorityEncoder that selects the first free physical register from the free list. To prevent multiple lanes from allocating the same physical register, lane i’s priority encoder input filters out any physical register already selected by lanes 0 through i-1, creating a forward dependency chain across lanes.

The key addition is destination register forwarding during source operand lookup. When lane k looks up the physical register for a source architectural register, it first reads the current mapping from the rename table, then checks whether any previous lane m (where m < k) in the same fetch block is allocating a new physical register for the same architectural register. If so, lane k uses lane m’s newly-allocated physical register instead of the stale table entry. This ensures that within a single fetch block, a later instruction correctly reads from the destination of an earlier instruction (e.g., add x1, x2, x3 followed by add x4, x1, x5 in the same block will have the second instruction’s x1 source point to the physical register just allocated by the first instruction).
