Writeback Commit Unit (WCU)

WritebackCommitUnit L4

The level 4 Writeback Commit Unit (WCU L4) is responsible for arbitrating between completed instructions from multiple execute units (XUs) and reordering them for in-order commit, just as the previous versions. However, the L4 WCU supports a superscalar architecture, allowing it to arbitrate multiple completed instructions to send to the ROB, which, in turn, can also commit multiple instructions in the same cycle.

The WCU L4 pipeline consists of three main stages: (1) arbitration and selection, which picks up to p_num_be_lanes completed instructions from the p_num_pipes execute pipes; (2) completion notification, which broadcasts the selected instructions’ write-back data to the decode-issue unit’s rename table and register file before entering the FIFO; and (3) reorder and commit via the MROB, which buffers instructions and dequeues them in program order.

The arbiter is configurable via the p_use_age_arb parameter: when set (the default), the age-based SSWCUArb is used; when cleared, the round-robin MRRArb is used instead. Both arbiters receive a budget (avail_slots_arb) computed as the minimum of the MROB’s available slots and the number of backend lanes, capped further when the bypass FIFO is full. A WCUBypassFifo sits between the arbiter output and the MROB, decoupling the arbitration stage from the reorder buffer.

Age-Based Instruction Arbiter: SSWCUArb

The age-based arbiter (SSWCUArb) selects up to m of the oldest requesting pipes each cycle using the shared ISLIPCore matching engine. It is the default arbiter for the WCU L4 and is analogous to the SSDIURouter used on the decode-issue side, but routing in the opposite direction (N pipes → M backend lanes).

SSWCUArb builds a compatibility matrix where every valid pipe is compatible with every backend lane, then limits the number of active output lanes via an output_free_init mask derived from the m budget. ISLIPCore performs the matching using an age-based grant phase (each output lane grants to the oldest requesting pipe via AgePE) and a lowest-index accept phase (each pipe accepts the lowest-indexed output lane that granted to it). Age comparison uses SSSeqAge with the oldest committed sequence number for wrap-around-safe ordering.

After matching, granted pipes are packed into sequential output lanes and ready signals are driven back to the execute interfaces.

Round-Robin Instruction Arbiter: MRRArb

The multi-round-robin arbiter (MRRArb) is the alternative arbiter, selected when p_use_age_arb is 0. It selects multiple completed instructions from multiple XUs using a round-robin priority scheme. This paper describes an implementation for an m-select round-robin arbiter, which performs exactly the operation desired for this case, albeit with a fixed number of instructions to output at once. Our implementation is based on this design, but modified to allow for a variable number of instructions to be selected based on the number of available slots in the ROB, which is communicated to the arbiter as the avail_slots signal seen in the above diagram.

The paper describes the implementation in detail. The design is centered around two m-select priority encoders, which select up to m inputs from a set of n inputs based on a priority scheme. This is done by using a saturated sum, which iterates through each input request and adds to a running total of requests until it hits a maximum of m requests, at which point it stops adding to the total. From the sum at each index, we can use edge detection to find the index of the first m or fewer requests, which are then output as thermo-encoded vectors to represent each index.

In the diagram, mPEth1 selects up to m inputs from the inputs at the index indicated by the head pointer up to the most-significant input, while mPEth2 selects up to m inputs from all of the inputs without considering the head-pointer. This is necessary, as using a single priority-encoder would require us to “wrap around” the inputs, which is not possible in a straightforward manner. The outputs of these two encoders both produce up to m selected inputs, which are then combined using a series of muxes to select a final set of up to m selected inputs, giving priority to the grants given in mPEth1 as these represent the highest-priority inputs based on the round-robin scheme with the head pointer. These final up to m thermo-encoded grants are then edge detected to get a one-hot representation of the corresponding index, and then OR’d to produce a final one-hot output of selected inputs.

The head pointer is also updated based on the final up to m grants. The grants from mPEth2 are used to select the grant to use to update the head pointer as the order reflects the original request order. The final selected grant is then rotated by one to get the next highest-priority input for the next cycle, which is stored in the head pointer register.

When MRRArb is used, an additional selection mux packs the granted pipe data into sequential output lanes, and ready signals are driven directly from the grant vector.

Bypass FIFO: WCUBypassFifo

The WCUBypassFifo is a multi-lane FIFO that sits between the arbiter output and the MROB. It wraps a FifoBypass and packs all p_num_be_lanes lanes into a single FIFO entry. The FIFO is pushed whenever any selected instruction is valid and there is space, and popped whenever it is not empty. Completion notifications are driven from the arbiter output (before the FIFO) to minimize the latency of broadcasting write-back results to the rename table and register file. The FIFO depth and bypass behavior are controlled by the p_x_intf_fifo_depth and p_x_intf_fifo_bypass parameters.

Multi-Reorder Buffer (MROB)

The multi-reorder buffer (MROB) is responsible for storing the completed instructions from the WCU and committing them in order. The MROB is similar to the previous ROB, but modified to allow for multiple instructions to be enqueued, as well as dequeued at once, with support for bypassing enqueued instructions directly to be dequeued in the same cycle.

Supporting multiple enqueues is rather simple, as we can use multiple write ports to write multiple instructions to the buffer in the same cycle as long as the corresponding index does not currently hold an instruction. However, this should always be the case as the indices in the ROB corresponding to the sequence number of the instruction being enqueued, and only one instruction with that sequence number should ever be in flight in the processor at once.

Dequeuing multiple instructions simultaneously is more complex, as instructions can fill in entries in the ROB out of order, thus we may not have a contiguous range of entries starting at the dequeue pointer to dequeue in the same cycle. Complicating this further, there may be instructions to be enqueued on the next cycle that would fill in such gaps, allowing us to actually dequeue such an instruction in the current cycle so long as we bypass storing it in the entry registers.

To solve both of these issues, we first maintain a series of shadow registers which represent what the entries would look like if any enqueues on the current cycle were to be completed. This allows us to see what entries would be filled after the enqueues, and thus determine how many instructions can be dequeued contiguously starting from the dequeue pointer in order to support bypassing. At this point, we can then determine how many instructions to dequeue, where the first such instruction to dequeue is that at the dequeue pointer. If the number of instructions to dequeue wraps around the end of the buffer, we would need to perform “wrap-around” calculations which can be quite costly. To resolve this, we get a rotated and packed version of the valid bits of each entry, such that the LSB corresponds to the current index of the dequeue pointer, thus simplifying the problem to a linear iteration from the LSB. To figure out how many of these entries can be dequeued, we use edge detection to get the value of the first 1-to-0 transition of valid bits starting from the LSB, which indicates the first invalid instruction and thus where we must stop dequeuing since we must dequeue all ready instructions in order. The thermo-encoded version of this first edge, limited to the number of available superscalar lanes, represents the bitmask for the entries to dequeue, and the value of the first invalid index is used to update the dequeue pointer.

Using the value of the first invalid index, the value of the dequeue pointer is updated to this position for the next cycle. However, the added value is also limited by the number of available superscalar lanes, which may be less than the number of instructions that could be dequeued. Additionally, the number of available slots is calculated simply by checking which entries are not valid, and output to be used by the MRRArb to limit the number of completed instructions to enqueue.
