Writeback Commit Unit (WCU)

The Writeback-Commit Unit (WritebackCommitUnit) arbitrates between completed instructions arriving from the execute units, reorders them into original program order, and commits them to update the architectural state in the register file. The WCU accepts up to p_num_pipes completing instructions per cycle (one from each pipe in the backend) and commits up to p_num_be_lanes instructions per cycle.

The unit is structured as a two-stage pipeline. The first stage arbitrates between the p_num_pipes completing pipes to pick up to p_num_be_lanes of them and broadcasts the selected instructions’ writeback data over CompleteNotif to the rename table and register file in the DIU so that dependent instructions waiting in the issue queues can be marked ready as soon as possible. The second stage enqueues those selected instructions into the multi-reorder buffer (SSROB), which holds them until they can be dequeued and committed in program order.

Age-Based Instruction Arbiter: SSWCUArb

The age-based arbiter (SSWCUArb) selects up to m of the oldest requesting pipes each cycle using the same ISLIPCore matching engine that the decode-issue unit’s instruction mapper uses. This makes the WCU’s arbiter the natural analog of the DIU’s mapper, only routing in the opposite direction (from p_num_pipes input pipes to p_num_be_lanes output backend lanes).

SSWCUArb builds a compatibility matrix where every valid pipe is compatible with every backend lane (any completed instruction can be packed into any output lane), then limits the number of active output lanes via an output_free_init mask derived from the number of available instructions to arbitrate (avail_slots_arb, computed as the minimum of the SSROB’s available slots and p_num_be_lanes and gated to zero when the decoupling FIFO is full). ISLIPCore then performs the matching using an age-based grant phase (each output lane grants to the oldest requesting pipe via AgePE) and a lowest-index accept phase (each pipe accepts the lowest-indexed output lane that granted to it). Age comparison uses SSSeqAge with the oldest committed sequence number for wrap-around-safe ordering.

After matching, granted pipes are packed into sequential output lanes and ready signals are driven back to the execute interfaces so the granted pipes can advance to their next completing instruction.

An earlier multi-select round-robin arbiter (MRRArb) based on this paper was the original implementation, but SSWCUArb replaced it once the iSLIP-based crossbar was already required on the decode-issue side – sharing one matching engine across both ends of the pipeline reduced overall complexity and gave the WCU age-aware arbitration for free.

Decoupling FIFO: WCUFifo

The WCUFifo is a multi-lane FIFO that sits between the arbiter output and the SSROB so the two stages can operate without back-pressuring each other. The FIFO wraps a generic Fifo and packs all p_num_be_lanes lanes into a single FIFO entry, with the depth set by the p_x_intf_fifo_depth parameter. The FIFO is pushed whenever any selected instruction is valid and there is space, and popped whenever it is not empty.

Importantly, the completion notifications that broadcast writeback data back to the rename table and register file in the decode-issue unit are driven directly from the arbiter output (before the FIFO) rather than from the FIFO output. This minimizes the latency of communicating writeback results to the issue queues so that dependent instructions can be marked ready and dispatched on the same cycle that the completing instruction is selected by the arbiter, without having to wait for it to drain through the FIFO first.

Multi-Reorder Buffer: SSROB

The multi-reorder buffer (SSROB) stores instructions received from the FIFO and commits them back in program order to the rename table. It is similar to a traditional ROB but extended to allow multiple enqueues and dequeues per cycle, with the additional ability to bypass an enqueued instruction directly to a dequeue in the same cycle for the case where the entry being enqueued is exactly the one needed to make the dequeue range contiguous.

Supporting multiple enqueues is straightforward since the SSROB uses multiple write ports indexed by the sequence number of the instruction being enqueued. Only one in-flight instruction can carry a given sequence number at a time, so write conflicts cannot occur between simultaneously enqueueing instructions.

Supporting multiple dequeues is more complex. Instructions can complete and arrive in the ROB out of order, so the entries starting at the dequeue pointer may not all be valid in a single cycle. Additionally, instructions enqueueing on the current cycle may fill exactly the gaps that would otherwise block a dequeue, allowing those instructions to be dequeued in the same cycle so long as they are bypassed past the entry registers.

To handle both of these cases together, the SSROB maintains a set of shadow registers that represent what the ROB entries would look like if the current cycle’s enqueues had already been written to their respective entries. This shadow view is then used to determine how many contiguous valid entries exist starting from the dequeue pointer. To avoid expensive wrap-around calculations when the dequeue range crosses the end of the buffer, the shadow valid bits are rotated and packed so that the least significant bit corresponds to the entry at the dequeue pointer. This reduces the dequeue-range problem to a linear iteration from the LSB, where edge detection identifies the first 1-to-0 transition in the valid bits, which indicates the first invalid entry and therefore where dequeuing must stop. The thermo-encoded representation of this edge, further limited by p_num_be_lanes, gives the bitmask of entries to dequeue this cycle, and the index of the first invalid entry advances the dequeue pointer for the next cycle. The number of available SSROB slots, fed back as avail_slots to the arbiter to cap how many new instructions can be selected, is computed by counting the entries whose valid bits are not set.
